• Model NO.：DY-C4
• Laser Type：Q Switch YAG Laser+Laser Carbon Peeling
• Laser Handle：1064 , 532 Nm ,1320nm Carbon Laser Tip
• Energy Density：400mj~1000mj Adjustable (Peak Value up to 1500mj)
• Pulse Width：10ns
• Pulse Frequency：1-6Hz (1-10 Hz Available)
• Screen Display：7 Inch Color Touch Screen Display
• Cooling Mode：Internal Water Circulation+Double Fans+ Air Cool
• Power Supply：AC110V,10A, 60Hz, AC220V,5A,50Hz
• Dimension：33*33*90cm
• Net Weight：36kgs
• Transport Package：Wooden Package
• Specification：58cm*62cm*125cm
• Trademark：DANYE
• Origin：Guangzhou, China
• HS Code：8543709990
• Production Capacity：300,Month

Basic Info.

Model NO. DY-C4 Laser Type Q Switch YAG Laser+Laser Carbon Peeling Laser Handle 1064 / 532 Nm /1320nm Carbon Laser Tip Energy Density 400mj~1000mj Adjustable (Peak Value up to 1500mj) Pulse Width 10ns Pulse Frequency 1-6Hz (1-10 Hz Available) Screen Display 7 Inch Color Touch Screen Display Cooling Mode Internal Water Circulation+Double Fans+ Air Cool Power Supply AC110V/10A/ 60Hz, AC220V/5A/50Hz Dimension 33*33*90cm Net Weight 36kgs Transport Package Wooden Package Specification 58cm*62cm*125cm Trademark DANYE Origin Guangzhou, China HS Code 8543709990 Production Capacity 300/Month

Product Description

Can efficiently flash long life around 900000 shots!
CE, IEC60335, IEC61000, EN60601 Approval!



For nd yag laser tattoo removal function:
The Q-Switched Nd:YAG laser delivers light of specific wavelengths in very high peak energy pulses which are absorbed by the pigment in the tattoo and result in an acoustic shockwave. The shockwave shatters the pigment particles, releasing them from their encapsulation and breaking them into fragments small enough for removal by the body. These tiny particles are then eliminated by the body.

Since the laser light must be absorbed by the pigment particles, the laser wavelength must be selected to match the absorption spectrum of the pigment. Q-Switched 1064nm lasers are best suited for treating dark blue and black tattoos, but Q-Switched 532nm lasers are best suitable for treating red and orange tattoos.

For Black face therapy function:
Its principle is to use very subtle carbon powder coated onto face, then laser light through special carbon tip gently irradiate onto face to achieve beauty effects, the melanin of carbon powder on face can double absorb the heat energy, so the heat energy of light can penetrate into the oil secretion of pores by means of this carbon powder to open blocked pores and to stimulate collagen hyperplasia, thus achieve pore shrinking, skin rejuvenation, oily skin enhancement, etc


Technical specification:

Model	DY-C4
Laser type	Q switch yag laser+laser carbon peeling
Laser handle	1064 / 532 nm /1320nm carbon laser tip
Energy density	400mj~1000mj adjustable (peak value up to 1500mj)
Pulse width	10ns
Pulse frequency	1-6Hz (1-10 Hz available)
Screen display	7 inch color touch screen display
Cooling mode	Internal water circulation+double fans+ outside air cooling
Power supply	AC110V/10A/ 60Hz, AC220V/5A/50Hz
Dimension	33×33×90cm
Net Weight	36kgs

Treatment show &Function &Before and After photos:



Client's feedback:


Product display:


Certificates:



Company information:
