IPL+RF+E-Light Opt Laser Hair Removal Machine
Beijing Oriental Wison Technology Co., Limited- Type:Hair Removal Instrument
- Theory:IPL
- Application:Salon, Beauty Clinic, Beauty Center, Medical SPA
- Portable:Non Portable
- Spot Size:Hr:16*57mm,Sr:8*34mm
- Certifications:Medical Ce, Tga, FDA, ISO13485& Sfda
Base Info
- Model NO.:SMQ-NYC-3
- Wavelength:Hr:690-1200nm,Sr:560-1200nm
- Light Source:IPL
- Feature 1:Hair Removal, Skin Rejuvenation, Vascular Removal
- Feature 2:Pigment Lesions,Ance
- Warranty:One Year and Lifetime Maintenance
- Screen:10.4 Inch Touch Screen
- Cooling System:Semiconductor+Water+Wind Cooling
- Power:2000W
- Transport Package:International Standard Package
- Specification:525*490*1015mm(W*D*H)
- Trademark:Monalisa
- Origin:China
- Production Capacity:10000PCS,Year
Description
Basic Info.
Model NO. SMQ-NYC-3 Wavelength Hr:690-1200nm,Sr:560-1200nm Light Source IPL Feature 1 Hair Removal, Skin Rejuvenation, Vascular Removal Feature 2 Pigment Lesions,Ance Warranty One Year and Lifetime Maintenance Screen 10.4 Inch Touch Screen Cooling System Semiconductor+Water+Wind Cooling Power 2000W Transport Package International Standard Package Specification 525*490*1015mm(W*D*H) Trademark Monalisa Origin China Production Capacity 10000PCS/YearProduct Description
IPL+RF+E-Light Opt Laser Hair Removal Machine
1. Introduction:
NYC3 is also an Intensive Pulse Light(IPL) treatment therapeutic machine in a vertical type.
NYC3 is Sincoheren's third generation of Intense pulsed light therapeutic machine,it has a 10.4inch touch panel controller,a user-friendly multi-language operating system,with the adoption of perfect pulse technology,stable and even outputing of the energy can be easily realized,the standard configuration of this machine contains a HR handpiece with big size light spot and a SR handpiece with small size light spot.
2. Indications:
1. Hair removal, skin rejuvenation
2. Wrinkles reduction, skin tightening
3. Lighten and eliminate acne scars
4. Skin whitening and increase the elasticity
5. Vascular lesions (telangiectasis) and bottle nose
6. Remove freckles, pigmentations, age spots and sun spots
3. Trait and advantage:
1. Portable design, which is convenient for you to carry and move. Large touch screen for simple operation.
2. Efficient Hair-removal: Super big spot hair-removal hand piece makes efficiency 2 times to general hand piece, at same time to save cost of exchanging hand piece.
3. Super big spot (16*57mm) handle piece makes the treatment more quickly, and the normal spot (8*34mm) handle piece can be used for small area treatment.
4. Semi-conductor cooling system would make the temperature of hand piece crystal reach at -4°C during 5 minutes after turning it on, which ensures IPL treatment safe and comfortable. Lower temperature cooling system makes it more effective and comfortable.
5. Certified by FDA, Germany TÜV Rheinland ISO 13485 and Medical CE
4. Advantages:
1,FDA,Medical CE,TGA ceratificate are approved,which guarantee our machine quality and safe.
2,Super strong IPL supply for 2000W,which guarantee enough energy output for continuous working.
3,Fast repetation rate max 10shots/second with mode.
4,TDK-Lambda switch power is supplyed from Japan,making energy output more precise.
5,Powerful cooling system,power 100w with semiconductor cooling,making the treatment more comfortable.
And for this machine,we have five skin types and body parts to choose,when you choose one skin type and one body part,the parameter will be seted for advice.our company produced and exported beauty machine since 1999.we own research and development team,and also many clinical data from feedbacks of clients,this is why our machine have good treatment results and more better to meet clients requirement.
5. Technical Parameters:
Light source | Xenon lamp |
Spectrum | HR 690-1200nm SR 560-1200nm |
Fluence | HR 5-45J/cm² SR 5-40J/cm2 |
Pulse duration | 5-9.9ms for IPL mode 2-10ms |
Pulse delay | 5-60ms for ipl mode |
Spot size | 16×57 mm2 for HR1 8×34 mm2 for HR2 |
Cooling | Semiconductor cooling, water cooling and air cooling |
Skin cooling | Contact skin cooling technology |
Electrical | 110-240VAC 50-60Hz 1200VA |
Dimension(W×D×H) | 525mm×490mm×1015mm |
Frequency | 1-10HZ |
Repetition rate | 2-10 for FP |
Net Weight | 45Kg |
